Description
Specification:
Type | Conductor (mm2) | Messenger Diameter (mm) | Breaking Load (KN) |
GB1 | 4 x (35-50) | 11-14 | 15 |
GB2 | 4 x (70-95) | 14-16 | 20 |
GB3 | 4 x (50-120) | 11-17 | 20 |
Structure Feature
1.Iron braces are made of steel strap with surface galcanized.
2.Wedges are made of weather resistant and anti-UV material with high mechanical strength.
3.Equipped with bolts.
4.Strong springs between wedges facilitate the insertion of conductors.
5.No loose parts could fall off during installation.
